Note. Please fill the blanks in details, which will be an important date for the idler design.
①Material Transported Kind ⑥Roller Seal Structure
Apparent Specific Gravity Ton/㎡ Grease
Temp ⑦Running Condition Temp Max. ℃, Min.
Max. Matl Size mm Condition of Material Dry. Sticky. Wet Oily Or Other
②Capacity of Transportation Ton/Hr Running Time Hour/Day
③Belt Width mm ⑧Painting (Standard)
  Roller Stand
④Belt Speed m/min Paint Grade Ackyd-Resin And Anti Corrosive Paint Chlorinated Rubber Paint
Color Black Grey
⑤Belt Weight kg/m If Required, Inform US The Painting Specification
Paint Grade
Color
Kind of Idler Belt Direction (Reversible or Not) Roller Dimension (Out Dia×Length) Trough Angle Bearing No. Pitch (M) Q'TY (Set) Stand & Bracket (Need or Not)
①Carrying
②Impact
③Return
④Spiral Return
⑤Rubber Disc Return
⑥Suspended
⑦Self Aligning Carrying
⑧Self Aligning Return
⑨Transition
⑩Inverted V-Type Return
⑪Scale Carrying
